ABT100 User Manual
Revision 1.01 — Dec 1, 2025 — Release (covers ABT100 / ABT110 family)
This manual covers the ABT100 family trackers (including ABT110 / ABT110M). Use the structured sections below for quick reference, or open the full PDF for diagrams and the complete document.
Introduction
The ABT100 is a powerful tracking device with a built-in Cat 1 network module, designed for demanding applications such as asset tracking, vehicle recovery, and cold chain logistics. It includes a motion sensor, light sensors, BLE 5.3, and a 10000 mAh battery. The device is rated IP67.
ABT100 is available in several versions:
- ABT100 — Standard version
- ABT100M — Standard version + magnet
- ABT110 — Standard version + RF433 transmission
- ABT110M — Standard version + RF433 transmission + magnet
Specifications
| Parameter | Value |
|---|---|
| Dimensions | 111.5 mm × 67.9 mm × 31.5 mm |
| Network | EGPRS: GSM850/GSM900/DCS1800/PCS1900; Cat-1: B1, B3, B5, B7, B8, B20, B28 |
| GNSS (optional) | GPS, GLONASS, BDS, Galileo |
| Bluetooth | BLE 5.3 |
| Sensors & interface | G-Sensor (6-axis accelerometer and gyroscope); light sensor front & back (tamper); temperature and humidity |
| Battery | 3.7 V 10000 mAh rechargeable Li-polymer |
| IP rating | IP67 |
| Power supply | 5 V 3 A |
| Operating temperature | −20 °C to +60 °C |
| LED indicators | NET LED; GNSS LED; Battery LED |
| Configuration / charging port | External 4-pin port |
| RF433 transmission | Optional (depends on model) |
| Magnet | Optional (depends on model) |
Install a SIM card
Open the case and ensure the unit is not powered. Slide the holder down to open the SIM card holder. Insert the SIM card with the gold-colored contact area facing down, aligning the cut mark. Close the SIM card holder, then close the case and fasten the screws.
Battery & charging
The unit has an internal 10000 mAh rechargeable Li-polymer battery. Typical charging time is about 5 hours. The unit can be charged from a computer or with an external power adapter at 5 V 3 A.
Terminal status LED
GNSS LED
| Device status | LED status |
|---|---|
| GNSS chip is powered off | Off |
| GNSS sends no data or data format error occurs | High-speed flashing |
| GNSS chip is searching GNSS information | Medium-speed flashing |
| GNSS chip has gotten GNSS information | On |
NET LED
| Device status | LED status |
|---|---|
| The device is searching network | Fast flashing |
| The device has been registered on the network | Slow flashing |
Battery LED: when the button is pressed, the battery LED indicates the battery level.
G-Sensor (motion)
The unit has an internal 6-axis accelerometer and gyroscope sensor supporting motion detection and tilt alarm.
RF433 transmission
RF433 transmission is only available on ABT110 or ABT110M units.
Product parts list
| Name | Notes |
|---|---|
| ABT100 | Tracker unit |
| 6 pcs screws | Case fastening |
| Charging adapter with charging cable | 5 V supply |
ABT110 — User manual
